CATIA V5 to/from CADDS Translator

Read and write data between the two systems

The CADTranslate Solution

This CADTranslate product (previously CADverter) is a direct database converter between CADDS5 and CATIA V5. It enables the user to convert all forms of mechanical design geometry, as well as assembly and attribute information, between these two systems.

The translator can be purchased as a uni-directional, CADDS to CATIA V5, or CATIA V5 to CADDS product, or as a bi-directional product. It can be used interactively or in a batch mode, from a standard G.U.I Interface.

Key Features

  • This translator reads and writes CADDS data independent of the native CAD System
  • The translator converts all geometry.
  • If assembly data (product structure) is in the file, the assembly structure will be mapped between the two systems as well as colour and layer information.
  • The user can filter data to optimize the process.
  • If you wish to visualise and interrogate the CADDS files this can be done by using the integrated CADviewer, which is included with this CADTranslate product.

Legacy Data Migration Services

For companies wishing to migrate their legacy CADDS or CATIA V4 data to an alternate system we can provide a data migration service, where we take your data and migrate it to the system of your choice on an agreed cost basis.

A Logical Approach to CAD Data Exchange

What should you consider when starting a CAD Data Exchange project?

This article aims to help people highlight, and then side-step, common problems that may occur during their data exchange lifecycle.
