Release more value from your proprietary 3D CAD assets by using Publish to 3D PDF or Composer, to create rich intelligent documents with text and 3D content.
Interactive 3D documents enrich your supplier and partner communications at low cost. They provide a full 3D definition of your data whilst protecting your intellectual property.
Use 3D documents for internal 3D content sharing, or to create Work Instructions, RFQ’s, Training and Sales Documents or for supplier communication. Because they contain rich content including PMI data, they provide an effective solution for delivering Model Based Engineering data for a wide range of consumers.
3D documents can be created directly from your CAD session, just “save as” or if you have higher volumes of data they can be run in batch mode and integrated into your PLM system.
3D PDF is a standard PDF document containing 3D CAD content as a PDF file which has a wide range of uses and is free to consume.
Are a set of tools for the CATIA V5, 3D Experience and SolidWorks user for creating and publishing rich documents with 3D content including JT files.
If you’re unaware of 3D PDF, then you would be forgiven for assuming that the 3D content would be a static image, or maybe an object that could rotate.
